Groeneveld

Short Description:

Since its foundation in 1971 in Gorinchem Netherlands, Groeneveld has developed into a global enterprise with approximately 700 employees.


Product Detail

Product Tags

Since its foundation in 1971 in Gorinchem Netherlands, Groeneveld has developed into a global enterprise with approximately 700 employees. Groeneveld, part of The Timken Company, has around 30 branches, resulting in a worldwide coverage. The product widely used for port equipment, earthmoving & construction, mining,  transportation, agricultural, wind etc.

The OEM for application of port equipment industry include: ZPMC, KalmarLiebherr Konecranesetc. The end user includeDPW, PSA Singapore RWG HPH Mexico Auckland Shanghai port Qingdao port Guangzhou port etc.

The OEM for application of construction include Komatsu Volvo Liugong CAT etc.

As for AGV application, the product also widely used for ZPMC Siasun Kalmar VDL, The twin system also applied for container spreader like ZPMC RAM BROMMA and Stinis etc.

Specification sheet
Twin XL dual-line automatic lubrication system
Dimensions

Translube07

Version

Article code Capacity reservoir Supply voltage Grease delivery Max. operating pressure
F126630 18 litre 24 Vdc 20 cc/min 250 bar

Basic information

Pump type Electric piston pump (5 pistons)
Operating principle Parallel (dual-line)
Output 1
Max. number of lubrication points 200*
Cartridge or refillable Refillable
Grease class up to NLGI-2
Temperature range - 20 °C up to + 70 °C
Controlled by Timer
Interval Variable
Supply voltage 24 Vdc
Rating pump motor 4 A at 20 °C / 15 A at -20 °C
Rating pump motor nominal Pump engine: 36 W / solenoid valve 30 W
Connection type 8-pin TYCO
Valve type Double solenoid valve 5/2-valve
Weight (excl. grease) 23 kg
Protection class IP67 (pump unit)

Translube8

Translube09
